Fully Automatic Test Process, improve quality, save manpower cost

High throughput 150 tests/hour, meet the needs of laboratory change and development

Easy operation, quantitative result, get result within 15 minutes

Operation System:

Fully automatic, 25 test channels, Built-in control unit; touch screen operation, easy operation; High accuracy

Sample loading Capacity:

50 sample tubes can be uploaded at one time; The sample can be automatically identified to match the selected test item

Sampling:

Automatically sampling, automatically detect sample level, automatically incubate, testing, discarding used cards

Reaction System:

100 test cards can be uploaded at one time; Built-in 25 incubation positions, 96 TIP racks, a 96-hole dilution plate, 4 dilution bottle positions, which can store 4 kinds of buffer or diluent bottles

Output/Print:

Support bidirectional communication to LIS system, printed on the specified printer, or built-in thermal printer

External Interface:

Support COM, USB, network port etc. external port. Support 4G, and remote quality control, and remote calibration curve upgrade

Size/Weight:

915mm(L)X520mm(W)X700mm(H); Weight 117kg
