High frequency dynamic generator

Self-developed high frequency dynamic generator, provide both radiography and fluoroscopy working mode;

Highly precise adjustment of exposure parameters (kV, mA and s) for stable and homogeneous radiation emission.

1. Output power: 65.5KW

2. High Working Frequency: 500kHz

3. Maximum Tube Voltage: 40- 150KV(radiography) / 40-125kV(fluoroscopy)

4. Maximum Tube Current:10-800mA(radioraphy)/5-20mA(pulsed fluoroscopy)

Dynamic Flat Panel Detector with High Frame Rate

High resolution images without geometric distortion for precise clinical diagnosis.

1.The large FOV: 427*427mm

2. Pixels: 3072*3072

3. Pixel Size: 139μm

4. Grey Scale:16 bits

5. Highest acquisition speed: 30 frames/second

Double high density grids as standard (1m and 1.8m)

Removable grids for low dose examinations. Suitable for dose sensitive patients like children.

High thermal capacity X-ray tube (Canon brand)

High thermal capacity X-ray tube ensure long time working hours

1. Rotating anode: 9700rpm

2. Dual Focus: 0.6/1.2mm

3. Anode Thermal Capacity:400kHu
